FEATURE:
-
Four input channel functions
are automatically selected in the preset priority sequence.
-
Easy-to-sing high performance
digital echo.
-
Effector terminal which
permits connection of a graphic equalizer.
-
Five microphones can beused
simultaneously, one of which independently permits ON/OFF of
echo for use by an emcee.
-
Low-impedance compatible power
amplifier configuration that can drive two sets of speakers
simultaneously.
-
A ¡Ó4-position key controller
that can vary up to 2.5 pitch (chromatic intervals) is
incorporated. at the end of a tune. The Standard pitch is
resumed automatically.
-
A wireless remote control
which permits remote control of music volume, microphone
volume, echo level, key control and echo mode.
-
4 Video Input ,1 Video Output
(RCA)
-
1 Stereo Output
|
|
Specification \ Model |
MA
3600S |
|
Audio output power (1 KHz
8£[) |
200
W + 200 W |
| Total
Harmonic Distortion (1 KHz, 60W , 8£[) |
0.05% |
|
Audio input jacks
(Sensitivity/Impedance) |
¡@ |
| MIC
|
9mV / 2 K£[ |
|
BGM , DVD, CD, AUX |
300mV 51 K£[ |
| Frequency
Response |
¡@ |
|
MIC |
40
Hz to 15KHz, ¡Ó3 dB |
| MUSIC |
20 Hz to 20 KHz ¡Ó 2dB |
|
Tone control
characteristics |
¡@ |
| Music |
BASS |
¡Ó 12 dB (100 Hz) |
| ¡@ |
MID |
¡Ó 8
dB (2 KHz) |
| ¡@ |
TREBLE |
¡Ó 12 dB (10 KHz) |
|
Microphone |
BASS |
¡Ó 12
dB (100 Hz) |
| ¡@ |
MID |
¡Ó 8 dB (2 KHz) |
| ¡@ |
TREBLE |
¡Ó 12
dB (10 KHz) |
| Speaker Impedance |
4£[ ~ 16£[ (
one channel only 1 or 2) |
| ¡@ |
8£[ ~ 32 £[ (two channel 1
and 2) |
| Key Control Range |
11 Steps +
2½ tones |
|
Video Input Jack |
¡@ |
¡@ |
|
(Sensitivity / Input Impedance) |
1 Vp-p / 75 £[ |
|
Video Output Jack |
¡@ |
¡@ |
|
(Output
level / output impedance) |
1 Vp-p / 75 £[ |
|
Power Supply Voltage |
AC
230 V/ 50 Hz |
| Power
Consumption |
800 W |
|
AC Power Outlets |
SWITCH x 2
(TOTAL MAX x 220 W) |
| ¡@ |
UNSWITCHED x 1
(TOTAL MAX x 220 W) |
|
|
